AEC120 RCBO Electronic 1M 1P 10kA C-20A 100mA AC Class

Specifications:

• Architecture
  • Neutral position

    • right
  • Number of poles

    • 1 P
  • Type of pole

    • 1 P
  • Curve

    • C
• Main electrical features
  • Rated operational voltage Ue

    • 230 / 240 V
  • Frequency

    • 50 Hz
  • Rated current

    • 20 A
• Voltage
  • Rated insulation voltage

    • 250 V
  • Max operating voltage

    • 253 V
  • Rated impulse withstand voltage

    • 4000 V
• Electric current
  • Rated residual operating current

    • 100 mA
  • Rated short circuit breaking capacity Icn under 230V AC according IEC60898-1

    • 10 kA
• Electric current / temperature
  • Rating current 30°C

    • 20 A
• Dimensions
  • Depth of installed product

    • 73 mm
  • Height of installed product

    • 115 mm
  • Width of installed product

    • 17,8 mm

• Power
  • Total power loss under IN

    • 5,76 W
• Endurance
  • Electric endurance in number of cycles

    • 2000
  • Number of mechanical operations

    • 1000
• Capacity
  • Number of modules

    • 1
• Installation, mounting
  • Tightening torque

    • 2,1Nm
• Standards
  • Standard text

    • IEC 61009-1
    • EN 61009-1
  • European directive WEEE

    • concerned
• Safety
  • Protection index IP

    • IP20
  • Residual current type

    • AC
