Description
NUMBER OF OUTPUTS C13: 8
PHASE: Single-phase
ELECTRICAL CONNECTION: Connecting cord with plug
MOUNTING DIMENSION (STANDARDIZED): 482.6 mm (19 inch)
WATTAGE: 3.84 kW max
FORM FACTOR: 1U
MOUNTING DIRECTION: Horizontal
NUMBER OF OUTPUTS C20: 2
AMPERAGE RATING: 16A
PACKAGE CONTENTS: ATS
Quickstart guide
Safety instructions
(2) Input cables: C19-C20 1.8m
(2) Input cable lockers
Plastic strips for output locking
RS-232 serial cable
Accessories for rack installation
INPUT CONNECTION: (2) C20
FITTED WITH: Display
Ampere Meter
LED indication
Mounting material
FREQUENCY RATING: 50/60 Hz
EVALUATION: Local
OPERATING TEMPERATURE: 0° to 40°C (32° to 104°F)
ETHERNET INTERFACE: No
NUMBER OF OUTLETS WITH EARTH PIN: 9
MASS CONFIGURATION: No
COMMUNICATION: No
SPECIAL FEATURES
Provides power redundancy to IT equipment
Alternative to expensive redundant power supplies available from networking equipment vendors
Compact, 1U rack form factor
Seamlessly switches from one power source to the other
LCD with metering and basic configuration capabilities
NUMBER OF OUTPUTS C19: 1
OUTLET CONTROL: No
SWITCHABLE: No
CORD LENGTH: 2m
INPUT VOLTAGE: 200-240V
COLOR: Black
SNMP: No
OVER VOLTAGE CATEGORY: 2
OUTLETS: (8) C13, (1) C19
TYPE: ATS
SERIAL INTERFACE: No
MOUNTING DIMENSION (METRICAL): 43
